250V 440V PDU Power Distribution Unit For Data Center Power Distribution

  • 1
  • 2

Brand Name : COOLNET

Model Number : Smart PDU

Certification : CE& ROHS

Place of Origin : CHINA

MOQ : 1 unit

Price : 50-500 USD per unit

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10000 unit per month

Delivery Time : 15 days

Packaging Details : Standard export packaging

Color : Black/WHITE

Rated Power : 250V 440V

Operating temperature : -10℃+75℃

Storage temperature : -40℃+80℃

Type of plug : Euro plug Customizable length

Switch Type : Built-in switch smart pdu

Relative humidity : 5~90%（no condensation）

Output digits : Maximum 48-bit output

Contact Now

COOLNET PDU for Data Center Power Distribution



Production



COOLNET PDUs can be used to input AC or DC high power AC power, equipped with high power air switches, output single or multiway grouped sockets, one PDU can meet the needs of the entire cabinet power distribution equipment, custom vertical type installation 0U, does not occupy space, easy to install, safe, stable, beautiful appearance, and can be combined with a variety of modules.

 250V 440V PDU Power Distribution Unit For Data Center Power Distribution



Product Features

250V 440V PDU Power Distribution Unit For Data Center Power Distribution
  • Built-in web server; through a web browser, the real-time power consumption of the distributor can be directly detected
  • When a power event occurs, the system administrator can be notified through Email Traps for processing
  • Provide central control software, user-friendly operation interface, easy monitoring
  • Can manage the power usage of a large number of distributors at the same time
  • Provide SNMP MIB, the network management system can directly integrate and monitor



Technological structure


  • Integrated red copper bar
  • Secondary protection grounding
  • Open type junction box
 250V 440V PDU Power Distribution Unit For Data Center Power Distribution

250V 440V PDU Power Distribution Unit For Data Center Power Distribution
Parameter



PDU



Parameters





input

 Input type AC single phase, AC three phase,-48VDC,240VDC,336VDC
Input mode

Transparent open type junction box,power cord, cable,

industrial connector, socket etc.
Input voltage range 100-277VAC/312VAC-418VAC/11VDC-240VDC/-43VDC- -56VDC
AC input frequency 50/60Hz
total load current MAX 63A





Output

 Storage temperature -40 - +70
Relative humidity 5-95% (No condensation)
Atmospheric pressure 70kPa - 106kPa
Working altitude No more than 4000M





Environmental

 Working temperature -10 - +75
Storage temperature -40 - +80
Relative humidity 5-95% (No condensation)
Working altitude No more than 4000M
IP rating IP20
Protection input protection module Circuit breaker, lightning protection, leakage protector, temperature insepction module (optional)
Output protection module Circuit breaker, fuse box, fuse(optional)



Certifications
250V 440V PDU Power Distribution Unit For Data Center Power Distribution
Case
250V 440V PDU Power Distribution Unit For Data Center Power Distribution



Factory
250V 440V PDU Power Distribution Unit For Data Center Power Distribution
